Mean Well IRM-03-15S AC/DC PSU 15V 200mA 3W compact low power consumption

Mean Well
Order Code:

05-0927

Brand: Mean Well MPN: IRM-03-15S EAN-13: 4021087034593
Qty Unit Price (Ex VAT)
1+ £6.28
5+ £6.07
10+ £5.89
25+ £5.81
50+ £5.71
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 26/12/2025

The Mean Well IRM-03-15S is an AC/DC power supply unit designed for PCB mounting. It delivers a 15 V DC output with a current rating of 200 mA and a power capacity of 3 W. This compact power supply is suitable for use in various electronic applications requiring reliable low-power DC voltage.
Number of Outputs 1
Output Power Max 3W
Output Voltage 15V DC
Output Current 200mA
Dimensions (L x W x H) 33.7 x 22.2 x 15 mm
Connection SMD
Consumption (standby) 75mW
Efficiency to 78%
Height 15mm
Input Frequency 47-63Hz
Input Voltage 305V AC
Length 33.7mm
Max. output current 200mA
Min. input voltage 85V AC
Operating Temperature -30°C to +85°C
Operating temperature (max.) +85°C
Operating temperature (min.) -30°C
Protection Class II
Residual ripple 200 mVp-p
Tolerance (output voltage) ±2.5%
Type AC/DC PSU (print)
Width 22.2mm
