Mean Well IRM-03-15 PSU 15V DC 200mA 3W compact size low power consumption

Mean Well
Standard range
Order Code:

05-0926

Brand: Mean Well MPN: IRM-03-15
Qty Unit Price (Ex VAT)
1+ £6.10
5+ £5.92
10+ £5.74
25+ £5.67
50+ £5.57
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
6 in stock, despatched in 4 working days

The Mean Well IRM-03-15 is an AC/DC printed circuit board power supply unit rated at 15 V DC and 200 mA with a power output of 3 W. It is designed for PCB mounting and includes solder lugs for secure connectivity. This compact power supply is ideal for applications requiring reliable, low-power DC voltage conversions on circuit boards.
Type AC/DC PSU (print)
Connection Pins
Consumption (standby) 75mW
Dim (L x W x H) 33.7 x 22.2 x 15 mm
Efficiency to 78%
Height 15mm
Input frequency 47-63Hz
Input voltage (max.) 305V AC
Length 33.7mm
Max. output current 200mA
Min. input voltage 85V AC
Misc Attribute IRM-03-15
No. of outputs 1
Operating Temperature -30°C to +85°C
Operating temperature (max.) +85°C
Operating temperature (min.) -30°C
Output current (max.) - rounded 200mA
Output voltage (max.) 15V DC
Power 3W
Protection class II
Residual ripple 200 mVp-p
Tolerance (output voltage) ±2.5%
Weight 24g
Width 22.2mm
