Mean Well IRM-02-9 AC/DC PSU 9V DC 222mA 2W compact low power IoT use

Mean Well
Order Code:

05-0923

Brand: Mean Well MPN: IRM-02-9 EAN-13: 4021087034647
Qty Unit Price (Ex VAT)
1+ £5.50
5+ £5.34
10+ £5.18
25+ £5.10
50+ £5.02
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well IRM-02-9 is a compact AC/DC PSU designed for PCB mount applications, providing a reliable 9 V DC output at 222 mA with a total power of 2 W. It features solder lugs for easy installation and is suitable for use in electronic devices requiring efficient power conversion. This power supply unit is ideal for low power industrial and consumer electronics projects.
Connection Pins
Consumption (standby) 75mW
Dim (L x W x H) 33.7 x 22.2 x 15 mm
Efficiency to 72%
Height 15mm
Input Frequency 47-63Hz
Input voltage (max.) 305V AC
Length 33.7mm
Max. output current 222mA
Min. input voltage 85V AC
Number of Outputs 1
Operating Temperature -30°C to +85°C
Operating temperature (max.) +85°C
Operating temperature (min.) -30°C
Output current (max.) - rounded 222mA
Output voltage (max.) 9V DC
Power 2W
Protection Class II
Residual ripple 150 mVp-p
Tolerance (output voltage) ±2.5%
Type AC/DC PSU (print)
Width 22.2mm
