Mean Well IRM-02-3.3 AC/DC PSU 3.3 V 600 mA 2 W compact for IoT sensors

Mean Well
Order Code:

05-0919

Brand: Mean Well MPN: IRM-02-3.3 EAN-13: 4021087034685
Qty Unit Price (Ex VAT)
1+ £5.85
5+ £5.68
10+ £5.51
25+ £5.43
50+ £5.35
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
28 in stock, despatched in 4 working days

The Mean Well IRM-02-3.3 is an AC/DC power supply unit designed for printed circuit board applications. It delivers a stable output of 3.3 V DC at 600 mA with a power rating of 2 W, ideal for PCB mounting. This compact PSU is commonly used in electronic devices requiring efficient power management and minimal space, such as communication equipment and industrial controls.
Connection Pins
Consumption (standby) 75mW
Dim (L x W x H) 33.7 x 22.2 x 15 mm
Efficiency to 66%
Height 15mm
Input Frequency 47-63Hz
Input voltage (max.) 305V AC
Length 33.7mm
Max. output current 600mA
Min. input voltage 85V AC
Number of Outputs 1
Operating Temperature -30°C to +85°C
Operating temperature (max.) +85°C
Operating temperature (min.) -30°C
Output current (max.) - rounded 600mA
Output voltage (max.) 3.3V DC
Power 2W
Protection Class II
Residual ripple 150 mVp-p
Tolerance (output voltage) ±2.5%
Type AC/DC PSU (print)
Width 22.2mm
