Mean Well HLG-40H-24AB LED driver 40W 24V dimmable outdoor PFC circuit

Mean Well
Order Code:

05-0850

Brand: Mean Well MPN: HLG-40H-24AB EAN-13: 4021087049443
Qty Unit Price (Ex VAT)
1+ £33.87
5+ £32.97
10+ £32.15
25+ £31.34
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well HLG-40H-24AB LED driver is a dimmable, constant voltage power supply offering 40.08 W output with an adjustable current range from 1 to 1.67 A. It is equipped with a 3-in-1 dimmer and PFC circuit, providing outdoor suitability, surge protection, and overvoltage safety, making it ideal for powering LED strips and other lighting fixtures on flammable surfaces and furniture. The driver is designed for compatibility with
Type LED driver
Connection Open end cable
Dim (L x W x H) 171 x 61.5 x 36.8 mm
Factory colour Metal
Height 36.8mm
IP Rating IP65
Length 171mm
Max. output current 1.67A
Max. power 40.08W
Max. temperature +80°C
Min. temperature -40°C
Misc Attribute 1 Constant voltage
Misc Attribute 2 Pulsed
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 1.67A
Output current (min.) 1A
Output voltage (max.) 27V DC
Output voltage (min.) 22V DC
Power range 40.08 W (max)
Test mark MM, SELV, UL, TÜV, CB, CE
Width 61.5mm
