Mean Well ELG-240-C2100B-3Y ELG series LED driver 241.5W 2100mA dimmable

The Mean Well ELG-240-C2100B-3Y LED driver provides a constant current output of 2100 mA with a power rating of 241.5 W, suitable for operating at a voltage range of 57 - 115 V DC. This dimmable driver is equipped with a 3-in-1 dimmer, and it includes features such as a PFC circuit, surge protection, and overvoltage protection, making it suitable for use on flammable surfaces

Type	LED driver
Output Voltage	57V DC
Max Output Power	241.5W
Output Current	2.1A
Input Voltage	100 to 305V AC
Colour	Metal
Connection	Open end cable
Dimensions	(L x W x H) 244 x 71 x 37.5 mm
Height	37.5mm
IP Rating	IP67
Length	244mm
Max. output current	2100mA
Maximum Temperature	+85°C
Min. temperature	-40°C
Misc Attribute 1	Constant current
Misc Attribute 2	Pulsed
Number of Inputs	1
Number of Outputs	1
Test mark	CE, CB, MM, UL, ENEC
Weight	1220g
Width	71mm
