Mean Well ELG-200-C2100DA-3Y elg series led driver 201.6w dimmable DALI

Mean Well
Extended range
Order Code:

05-0482

Brand: Mean Well MPN: ELG-200-C2100DA-3Y
Qty Unit Price (Ex VAT)
1+ £59.10
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack order, lead time 4 months

Mean Well's ELG-200-C2100DA-3Y is a constant current LED driver with a power rating of 201.6 W, providing 2100 mA at a voltage range of 48 to 96 V DC. This outdoor driver features a PFC circuit, surge protection, overvoltage protection, and is dimmable, making it suitable for use on flammable surfaces and furniture. It is ideal for powering LED strips and installations requiring stable current and dimming
Type LED driver
Connection Open end cable
Dim (L x W x H) 244 x 71 x 37.5 mm
Factory colour Metal
Height 37.5mm
IP rating IP67
Length 244mm
Max. output current 2100mA
Max. power 201.6W
Max. temperature +85°C
Min. temperature -40°C
Misc Attribute 1 Constant current
Misc Attribute 2 Pulsed
No. of inputs 1
No. of outputs 1
Output current (max.) - rounded 2.1A
Output voltage (max.) 96V DC
Output voltage (min.) 48V DC
Power range 201.6 W (max)
Test mark CE, CB, MM, UL, ENEC
Weight 1220g
Width 71mm
