Mean Well ELG-200-48AB-3Y LED driver 200W dimmable for outdoor use

Mean Well
Order Code:

05-0477

Brand: Mean Well MPN: ELG-200-48AB-3Y EAN-13: 4021087050425
Qty Unit Price (Ex VAT)
1+ £44.24
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well ELG-200-48AB-3Y is a LED driver with a constant voltage output of 44.8 - 51.2 V DC and current range between 2.08 - 4.16 A. It features a 3-in-1 dimmer, surge protection, and an adjustable PFC circuit, making it suitable for outdoor use and approved for flammable surfaces and furniture. Typical applications include powering LED strips and other LED lighting systems.
Type LED driver
Connection Open end cable
Dim (L x W x H) 244 x 71 x 37.5 mm
Factory colour Metal
Height 37.5mm
IP Rating IP65
Length 244mm
Max. output current 4.16A
Max. power 199.68W
Max. temperature +90°C
Min. temperature -40°C
Misc Attribute 1 Constant voltage
Misc Attribute 2 Pulsed
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 4.16A
Output current (min.) 2.08A
Output voltage (max.) 51.2V DC
Output voltage (min.) 44.8V DC
Power range 199.68 W (max)
Protection Class I
Test mark SELV, UL, MM, ENEC, CB, CE
Width 71mm
