Mean Well ELG-150-C1400B-3Y ELG LED driver 105W 1400mA dimmable outdoor

Mean Well
Standard range
Order Code:

05-0467

Brand: Mean Well MPN: ELG-150-C1400B-3Y
Qty Unit Price (Ex VAT)
1+ £44.15
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

The Mean Well ELG-150-C1400B-3Y is an outdoor-compatible LED driver providing a constant current of 1400 mA with a power rating of 105 W, operating within a voltage range of 54 - 107 V DC. Key features include dimmability using a 3-in-1 dimmer, PFC circuit for power efficiency, as well as surge and overvoltage protection, making it suitable for use on furniture and flammable surfaces. This robust
Type LED driver
Connection Open end cable
Dim (L x W x H) 219 x 63 x 35.5 mm
Factory colour Metal
Height 35.5mm
IP rating IP67
Length 219mm
Max. output current 1400mA
Max. power 105W
Max. temperature +90°C
Min. temperature -40°C
Misc Attribute 1 Constant current
Misc Attribute 2 Pulsed
No. of inputs 1
No. of outputs 1
Output current (max.) - rounded 1.4A
Output voltage (max.) 107V DC
Output voltage (min.) 54V DC
Power range 105 W (max)
Test mark CE, CB, MM, SELV, UL, ENEC
Weight 950g
Width 63mm
