Mean Well ELG-150-C1050B-3Y elg series LED driver 105W 1050mA 3-in-1 dimmer

Mean Well
Order Code:

05-0465

Brand: Mean Well MPN: ELG-150-C1050B-3Y EAN-13: 4021087038294
Qty Unit Price (Ex VAT)
1+ £35.59
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well ELG-150-C1050B-3Y LED driver provides a constant current of 105 W at 1050 mA within a voltage range of 72 - 143 V DC and includes a 3-in-1 dimmer. It is suitable for installation on flammable surfaces and approved for use on furniture, making it a reliable choice for both indoor and outdoor lighting applications. Featuring a PFC circuit, surge protection, and overvoltage safeguards, this versatile LED
Type LED driver
Connection Open end cable
Dim (L x W x H) 219 x 63 x 35.5 mm
Factory colour Metal
Height 35.5mm
IP Rating IP67
Length 219mm
Max. output current 1050mA
Max. power 105W
Max. temperature +90°C
Min. temperature -40°C
Misc Attribute 1 Constant current
Misc Attribute 2 Pulsed
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 1.05A
Output voltage (max.) 143V DC
Output voltage (min.) 72V DC
Power range 105 W (max)
Test mark CE, CB, MM, UL, ENEC
Width 63mm
