Mean Well DPU01M-15 DC/DC converter 1 W 2 outputs 1500 VDC insulation.

Mean Well
Order Code:

05-0409

Brand: Mean Well MPN: DPU01M-15 EAN-13: 4021087046176
Qty Unit Price (Ex VAT)
2+ £2.77
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
Available to back orderBack-order availability date - 15/12/2025

The Mean Well DPU01M-15 is a DC-DC converter module capable of delivering up to 1 watt of power with two output options and a current rating of 33 mA. This compact converter is suitable for applications requiring efficient power conversion and isolation in electronic circuits. Typical uses include powering small devices or modules that operate on a different voltage level within industrial or consumer electronic systems.
Connection Pins
Dim (L x W x H) 19.5 x 6.1 x 10.2 mm
Efficiency (max.) 78%
Height 10.2mm
Input voltage (max.) 13.2V DC
Insulation Voltage 1500V DC
Length 19.5mm
Max. output current 33mA
Min. input voltage 10.8V DC
Number of Outputs 2
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 33mA
Power 1W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 6.1mm
