Mean Well DPAN02C-15 DC/DC converter 2 outputs 67 mA 2 W wide temp range

Mean Well
Order Code:

05-0378

Brand: Mean Well MPN: DPAN02C-15 EAN-13: 4021087046381
Qty Unit Price (Ex VAT)
1+ £10.03
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well DPAN02C-15 is a DC/DC converter module with two outputs, rated at 67 mA and 2 W. It is designed for efficient conversion of direct current, making it suitable for applications in electronics and power supply systems. This module is typically used in environments where compact size and reliable power management are necessary.
Connection Pins
Dim (L x W x H) 21.8 x 9.2 x 11.1 mm
Efficiency (max.) 84%
Height 11.1mm
Input voltage (max.) 75V DC
Insulation Voltage 1500V DC
Length 21.8mm
Max. output current 67mA
Min. input voltage 36V DC
Number of Outputs 2
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 67mA
Power 2W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 9.2mm
