Mean Well DPAN02B-15 DC/DC converter 67 mA 2W 2 outputs 1500 V DC I/O insulation

Mean Well
Order Code:

05-0375

Brand: Mean Well MPN: DPAN02B-15 EAN-13: 4021087046411
Qty Unit Price (Ex VAT)
1+ £9.36
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well DPAN02B-15 is a 2 W DC/DC converter module designed for efficient power conversion with two outputs and a current rating of 67 mA. It is suitable for applications requiring reliable voltage regulation and isolation in diverse electronic systems. This converter is ideal for integration into circuit boards where compact and effective power management solutions are needed.
Connection Pins
Dim (L x W x H) 21.8 x 9.2 x 11.1 mm
Efficiency (max.) 85%
Height 11.1mm
Input voltage (max.) 18V DC
Insulation Voltage 1500V DC
Length 21.8mm
Max. output current 67mA
Min. input voltage 9V DC
Number of Outputs 2
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 67mA
Power 2W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 9.2mm
