Mean Well DPAN02A-15 DC/DC converter 67mA 2W 2 outputs 1500V insulation

Mean Well
Order Code:

05-0372

Brand: Mean Well MPN: DPAN02A-15 EAN-13: 4021087046442
Qty Unit Price (Ex VAT)
1+ £9.16
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well DPAN02A-15 is a DC/DC converter module with a current rating of 67 mA and a power output of 2 W, featuring two outputs. It is typically used in applications requiring voltage conversion and isolation in electronic systems. The converter is ideal for use in power supply designs that require efficient energy transfer and robust performance.
Connection Pins
Dim (L x W x H) 21.8 x 9.2 x 11.1 mm
Efficiency (max.) 83%
Height 11.1mm
Input voltage (max.) 18V DC
Insulation Voltage 1500V DC
Length 21.8mm
Max. output current 67mA
Min. input voltage 9V DC
Number of Outputs 2
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 67mA
Power 2W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 9.2mm
