Mean Well DPAN02A-12 DC/DC converter 2W 2 outputs 1500V insulation

Mean Well
Order Code:

05-0371

Brand: Mean Well MPN: DPAN02A-12 EAN-13: 4021087046459
Qty Unit Price (Ex VAT)
1+ £9.38
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well DPAN02A-12 is a DC/DC converter module with 2 watts of power and two outputs, drawing 83 mA. It is suitable for electronic applications requiring reliable voltage conversion and current rectification. Common uses include powering low-voltage circuits and providing isolation between different circuitry sections.
Connection Pins
Dim (L x W x H) 21.8 x 9.2 x 11.1 mm
Efficiency (max.) 82%
Height 11.1mm
Input voltage (max.) 18V DC
Insulation Voltage 1500V DC
Length 21.8mm
Max. output current 83mA
Min. input voltage 9V DC
Number of Outputs 2
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 83mA
Power 2W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 9.2mm
