Mean Well DKM10E-05 dkm029 series DC/DC converter 10W dual output 1A

Mean Well
Standard range
Order Code:

05-0351

Brand: Mean Well MPN: DKM10E-05
Qty Unit Price (Ex VAT)
1+ £23.65
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
3 in stock, despatched in 4 working days

The Mean Well DKM10E-05 is a DC/DC converter module with a current rating of 1 amp and a power rating of 10 watts. It features two outputs and is commonly used for converting direct current in electronic circuits. This converter is ideal for applications requiring efficient power management and reliable performance.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 25.4 x 25.4 x 10.2 mm
Efficiency (max.) 85%
Height 10.2mm
Input voltage (max.) 9V DC
Insulation voltage 1500V DC
Length 25.4mm
Max. output current 1A
Min. input voltage 4.7V DC
Misc Attribute DKM10E-05
No. of outputs 2
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 1A
Power 10W
PSU features DC-to-DC converter
Weight 18g
Width 25.4mm
