Mean Well DKM10A-12 DKM029 power-dense DC/DC converter 10 W dual output

Mean Well
Order Code:

05-0342

Brand: Mean Well MPN: DKM10A-12 EAN-13: 4021087046749
Qty Unit Price (Ex VAT)
1+ £25.60
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

Mean Well's DKM10A-12 is a DC/DC converter module with a total power rating of 10 watts and outputs two channels at 416 mA. It's designed for applications requiring stable voltage conversion and power isolation in industrial and telecommunication systems. The module is compact and efficient, making it ideal for space-constrained designs.
Connection Pins
Dim (L x W x H) 25.4 x 25.4 x 10.2 mm
Efficiency (max.) 87%
Height 10.2mm
Input voltage (max.) 18V DC
Insulation Voltage 1500V DC
Length 25.4mm
Max. output current 416mA
Min. input voltage 9V DC
Number of Outputs 2
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 416mA
Power 10W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 25.4mm
