Mean Well DETN02N-12 DC/DC converter 84mA 2W 2 outputs 1pc

Mean Well
Order Code:

05-0337

Brand: Mean Well MPN: DETN02N-12 EAN-13: 4021087052689
Qty Unit Price (Ex VAT)
1+ £7.68
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well DETN02N-12 is a DC/DC converter module with two outputs, rated at 84 mA and 2 W. It is commonly used for converting direct current in electronic applications, providing reliable power transformation. This module is suitable for use in printed circuit boards where space and efficient power conversion are crucial.
Connection Pins
Dim (L x W x H) 15.24 x 10.9 x 7.1 mm
Efficiency (max.) 80%
Height 7.1mm
Input voltage (max.) 26.4V DC
Insulation Voltage 3000V DC
Length 15.24mm
Max. output current 84mA
Min. input voltage 21.6V DC
Number of Outputs 2
Operating temperature (max.) +100°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 84mA
Output current (min.) 4mA
Power 2W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 10.9mm
