Mean Well DETN02M-12 Converter 2W 84mA 2 Outputs DC/DC Module 1pc

Mean Well
Order Code:

05-0333

Brand: Mean Well MPN: DETN02M-12 EAN-13: 4021087052719
Qty Unit Price (Ex VAT)
1+ £6.74
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well DETN02M-12 is a DC/DC converter module with two outputs designed for efficient power conversion, offering a current rating of 84 mA and a power output of 2 watts. This converter is suitable for applications requiring stable power supply in electronic circuits and devices. It is commonly used in telecommunications, industrial automation, and portable power systems.
Connection Pins
Dim (L x W x H) 15.24 x 10.9 x 7.1 mm
Efficiency (max.) 82%
Height 7.1mm
Input voltage (max.) 13.2V DC
Insulation Voltage 3000V DC
Length 15.24mm
Max. output current 84mA
Min. input voltage 10.8V DC
Number of Outputs 2
Operating temperature (max.) +100°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 84mA
Output current (min.) 8mA
Power 2W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 10.9mm
