Mean Well DETN02L-15 DC/DC converter 2 W 67 mA 2 outputs 1 pc

Mean Well
Standard range
Order Code:

05-0331

Brand: Mean Well MPN: DETN02L-15
Qty Unit Price (Ex VAT)
1+ £4.87
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
6 in stock, despatched in 4 working days

The Mean Well DETN02L-15 is a DC/DC converter module with 2 watts of power and an output current of 67 mA, featuring two outputs. It is typically used in applications requiring reliable power conversion, such as telecommunications and industrial electronics. This print converter module is ideal for environments needing efficient direct current conversion.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 15.24 x 10.9 x 7.1 mm
Efficiency (max.) 81%
Height 7.1mm
Input voltage (max.) 5.5V DC
Insulation voltage 3000V DC
Length 15.24mm
Max. output current 67mA
Min. input voltage 4.5V DC
Misc Attribute DETN02L-15
No. of outputs 2
Operating temperature (max.) +100°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 67mA
Output current (min.) 6mA
Power 2W
PSU features DC-to-DC converter
Weight 1.2g
Width 10.9mm
