Mean Well DETN02L-12 DC/DC converter 2W dual output 84mA 1pc

Mean Well
Standard range
Order Code:

05-0329

Brand: Mean Well MPN: DETN02L-12
Qty Unit Price (Ex VAT)
1+ £4.50
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

The Mean Well DETN02L-12 is a DC/DC converter module with a power output of 2 watts and a current rating of 84 mA. It features two outputs and is suitable for applications requiring reliable power conversion in compact settings. This converter is typically used in electronics where stable voltage conversion is needed.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 15.24 x 10.9 x 7.1 mm
Efficiency (max.) 80%
Height 7.1mm
Input voltage (max.) 5.5V DC
Insulation voltage 3000V DC
Length 15.24mm
Max. output current 84mA
Min. input voltage 4.5V DC
Misc Attribute DETN02L-12
No. of outputs 2
Operating temperature (max.) +100°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 84mA
Output current (min.) 8mA
Power 2W
PSU features DC-to-DC converter
Weight 1.2g
Width 10.9mm
