Mean Well DETN02L-05 DC/DC converter 2W 200mA 2 outputs 1pc

Mean Well
Order Code:

05-0328

Brand: Mean Well MPN: DETN02L-05 EAN-13: 4021087052757
Qty Unit Price (Ex VAT)
1+ £5.58
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
2 available to back orderBack-order availability date - 09/01/2026

The Mean Well DETN02L-05 is a DC/DC converter module with a power rating of 2 watts and dual outputs, each capable of providing up to 200 mA. This compact unit is ideal for applications requiring stable voltage conversion within electronic circuits. It is commonly used in telecommunications equipment, industrial control systems, and battery-operated devices.
Input Voltage Range 5.5V DC
Output Current 20mA
Number of Outputs 2
Connection Pins
Dim (L x W x H) 15.24 x 10.9 x 7.1 mm
Efficiency (max.) 78%
Height 7.1mm
Insulation Voltage 3000V DC
Length 15.24mm
Max. output current 200mA
Min. input voltage 4.5V DC
Operating temperature (max.) +100°C
Operating temperature (min.) -40°C
Power 2W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 10.9mm
