Mean Well DETN01L-15 DC/DC converter 1W dual output high efficiency

Mean Well
Standard range
Order Code:

05-0319

Brand: Mean Well MPN: DETN01L-15
Qty Unit Price (Ex VAT)
1+ £4.93
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
50 in stock, despatched in 4 working days

The Mean Well DETN01L-15 is a DC/DC converter module that delivers a power output of 1 W with a current rating of 34 mA and includes two outputs. It is typically used for voltage conversion and regulation in electronic circuits where space is limited, such as communication equipment and industrial control systems. This converter module is designed for efficient power management and reliable performance in various applications.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 15.24 x 10.9 x 7.1 mm
Efficiency (max.) 80%
Height 7.1mm
Input voltage (max.) 5.5V DC
Insulation voltage 3000V DC
Length 15.24mm
Max. output current 34mA
Min. input voltage 4.5V DC
Misc Attribute DETN01L-15
No. of outputs 2
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 34mA
Output current (min.) 3.4mA
Power 1W
PSU features DC-to-DC converter
Weight 1.2g
Width 10.9mm
