Mean Well DDR-480B-48 DC/DC converter 48 V 10 A 480 W 1 output

Mean Well DDR-480B-48 is a robust DC-DC converter designed to convert 48 V direct current with precision and efficiency. This converter is output rated at 480 W and 10 A, making it suitable for applications requiring a reliable power conversion solution. The device is engineered for use in industrial environments, commonly implemented in railway, automotive, or telecommunications systems where stable power supply is crucial under varying input conditions. The DDR-480B-48 provides a single output, facilitating straightforward integration in existing setups or new projects that demand high-performance voltage regulation and power rectification. The Mean Well product meets rigorous standards, ensuring dependable operation and compatibility with a wide range of power systems.

Power Rating	480W
Content	1
Dimensions	(L x W x H) 128.50 x 85.50 x 125.20 mm
Efficiency (max.)	90.5%
Height	125.20mm
Input voltage (max.)	33.6V DC
Insulation Voltage	4.000V
Length	128.50mm
Max. output current	10A
Maximum Temperature	+80°C
Min. input voltage	16.8V DC
Minimum Temperature	-40°C
No. of outputs	1
Output current (max.) - rounded	10A
Output voltage (max.)	56V
Output voltage (min.)	48V
Output voltages	48V
Power	480W
Product Type	DC/DC converter
PSU features	Adjustable voltage output
Type	DDR-480B-48
Weight	1375g
Width	85.50mm
