Mean Well DDR-120B-48 Rail DC/DC converter 48V 2.5A 120W 1 output

Mean Well
Order Code:

05-0271

Brand: Mean Well MPN: DDR-120B-48 EAN-13: 4021087051019
Qty Unit Price (Ex VAT)
1+ £70.81
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 20/12/2025

The Mean Well DDR-120B-48 is a rail mounted DC/DC converter designed for industrial applications, offering a stable 48 V DC output at 2.5 A with a power rating of 120 W. This single-output converter is easily mounted on a DIN rail, making it suitable for use in automated systems and industrial control environments. It provides reliable power conversion, ensuring efficiency and stability in various industrial settings.
Type Rail mounted DC/DC converter (DIN)
Output Voltage 48V DC
Output Current 2.5A
Number of Outputs 1
Power Rating 120W
Connection Clamp
Dim (L x W x H) 32 x 102 x 125.2 mm
Efficiency 91%
Height 125.2mm
Input Voltage 16,8-33.6V DC
Input voltage (max.) 33.6V DC
Length 32mm
Max. output current 2.5A
Min. input voltage 16.8V DC
MTBF 214600h
Nominal Input Voltage 24 V/DC
Operating temperature (max.) +70°C
Operating temperature (min.) -40°C
Output type (power supply units) Adjustable
Width 102mm
