Mean Well DCWN06A-05 DCWN06 series 6W DC/DC converter 2 outputs 500mA

Mean Well
Order Code:

05-0257

Brand: Mean Well MPN: DCWN06A-05 EAN-13: 4021087051156
Qty Unit Price (Ex VAT)
1+ £11.78
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well DCWN06A-05 DC/DC converter is a module with two outputs and a total power capacity of 6 watts, delivering up to 500 mA of current. It is typically used in applications requiring voltage conversion for electronic devices and systems. This direct current converter is suitable for environments where efficient power management is crucial.
Connection Pins
Dim (L x W x H) 31.8 x 20.3 x 10.2 mm
Efficiency (max.) 80%
Height 10.2mm
Input voltage (max.) 18V DC
Insulation Voltage 3000V DC
Length 31.8mm
Max. output current 500mA
Min. input voltage 9V DC
Number of Outputs 2
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 500mA
Power 6W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 20.3mm
