Mean Well DCWN03E-12 DCWN03 series DC/DC converter 3W 2 outputs

Mean Well
Order Code:

05-0255

Brand: Mean Well MPN: DCWN03E-12 EAN-13: 4021087046862
Qty Unit Price (Ex VAT)
1+ £10.51
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well DCWN03E-12 is a DC/DC converter module with a current rating of 125 mA and a power capacity of 3 watts, featuring two outputs. This converter is ideal for applications requiring efficient and reliable power conversion within electronic devices. Made by Mean Well, it is perfect for use in systems needing voltage conversion with stable performance.
Connection Pins
Dim (L x W x H) 31.8 x 20.3 x 10.2 mm
Efficiency (max.) 80%
Height 10.2mm
Input voltage (max.) 36V DC
Insulation Voltage 3000V DC
Length 31.8mm
Max. output current 125mA
Min. input voltage 9V DC
Number of Outputs 2
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 125mA
Power 3W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 20.3mm
