Mean Well DCWN03C-05 series DC/DC converter 3W 300mA 2 outputs DIP24

Mean Well
Order Code:

05-0251

Brand: Mean Well MPN: DCWN03C-05 EAN-13: 4021087046909
Qty Unit Price (Ex VAT)
1+ £7.94
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
1 available to back orderBack-order availability date - 09/01/2026

The Mean Well DCWN03C-05 is a DC/DC converter module delivering 3 W of power with a maximum current output of 300 mA. It features two outputs, making it suitable for applications requiring dual voltage conversion. This converter is typically used in electronic devices where efficient direct current conversion is necessary.
Input Voltage Range 72V DC
Output Current 300mA
Number of Outputs 2
Connection Pins
Dim (L x W x H) 31.8 x 20.3 x 10.2 mm
Efficiency (max.) 85%
Height 10.2mm
Insulation Voltage 3000V DC
Length 31.8mm
Max. output current 300mA
Min. input voltage 36V DC
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Power 3W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 20.3mm
