Kabeltronik 090260708 Strand Cable UL11028 1x0.14mm² Red 250m

Image Representative of Range

Kabeltronik 090260708 Strand Cable UL11028 1x0.14mm² Red 250m

Kabeltronik
Standard range
Order Code:

04-5021

Brand: Kabeltronik MPN: 090260708
Qty Was Unit Price (Ex VAT)
1+ £80.50   £74.60
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
1 in stock, despatched in 4 working days

Kabeltronik's 090260708 Strand is a red braid wire with a cross-section of 1 x 0.14 mm², supplied on a 250 m reel. It is ideally suited for internal and switchboard wiring applications, providing reliable conductivity and flexibility. This wiring braid is designed for precise electrical installations requiring compact and efficient circuitry.
Insulation material TPE
AWG 26
Bend radius (no. of ODs for fixed installation) 10
Bend radius (no. of ODs for flexible installation) 15
Cable type UL 11028
Certification marks UL, cUL
Core layout 7 x 0.16 mm
Cross section 1 x 0.14 mm²
Cross section (each core) 0.14mm²
Factory colour Red
Halogen-free Yes
Manufacturer part # 090260708
Max. temperature range (fixed installation) +105°C
Max. temperature range (flexible installation) +105°C
Min. temperature range (fixed installation) -40°C
Min. temperature range (flexible installation) -20°C
Misc Attribute 090260708
No. of leads 1
Nominal voltage 600V
RoHS-compliant Yes
Test voltage 6000V
Type Strand
