Finder manufactures the rail-mounted DIN PSU 78.60.1.230.2402, which delivers 24 V DC at 2.8 A with a power output of 60 W. This power supply unit is designed for easy installation on DIN rails, making it suitable for industrial applications. It's ideal for supplying power in automation systems, control panels, and other electrical installations.
| Type |
Rail mounted PSU (DIN) |
| Output Voltage |
24V DC |
| Output Current |
2.8A |
| Power Rating |
60W |
| 1st secondary output voltage |
24 - 28V |
| Built-in height |
N/A |
| Built-in width |
N/A |
| Degree of protection (IP) |
IP20 |
| Degree of protection (NEMA) |
N/A |
| Depth |
56.5mm |
| Direct mounting possible |
N/A |
| Efficiency |
91% |
| Height |
84mm |
| Input Voltage |
110 - 240V AC |
| IP Rating |
IP20 |
| Max. output current |
2.8A |
| Max. output current 1 |
2.8A |
| Max. output current 2 |
N/A |
| Max. output current 3 |
N/A |
| Max. temperature |
+70°C |
| Min. input voltage |
110V AC |
| Min. temperature |
-20°C |
| Misc Attribute 2 |
Switched PSU |
| Nominal Input Voltage |
110 - 240 V/AC |
| Nominal value output current 1 |
2.5A |
| Nominal value output current 2 |
N/A |
| Nominal value output current 3 |
N/A |
| Nominal value output voltage 1 |
24V |
| Nominal value output voltage 2 |
N/A |
| Nominal value output voltage 3 |
N/A |
| Output voltage stabilized |
true |
| Performance level according to EN ISO 13849-1 |
None |
| Power Consumption |
90VA |
| Power Output |
60W |
| Rated supply voltage AC 50 Hz |
110 - 240V |
| Rated supply voltage AC 60 Hz |
110 - 240V |
| Rated supply voltage DC |
220 - 220V |
| Secondary voltage adjustable |
false |
| Short-circuit-proof |
true |
| SIL according to IEC 61508 |
None |
| Stabilized |
true |
| Suitable for distribution board |
true |
| Suitable for rail mounting |
true |
| Suitable for safety functions |
false |
| Type of electric connection |
Screw connection |
| Voltage type (supply voltage) |
AC/DC |
| Wall mounting possible |
false |
| Width |
70mm |
| Width in number of modular spacings |
4 |
