EAO 46-2134.3120.000 Guarded push-button, maintained, red

EAOs 46-2134.3120.000 is a guarded, maintained push-button switch designed with a prominent red actuator. This device is specifically engineered for applications where safety and reliability are paramount. It features a robust mechanical design that ensures consistent operation and longevity under rigorous conditions. The products guarded design prevents accidental activation, making it ideal for use in industrial control panels, emergency stop functions, and machinery start/stop interfaces. Its utilisation in various engineering environments underscores its versatility.

Type	Pushbutton
IP Rating	Ip65
Climate Resistance	+25°c-97%rh / +45°c-93%rh (iec-en60068-2-30)
Conformities	Ce
Design	Raised
Erp Ehq Custom Number	8538.9000
Erp Ehq Source Country	It
Front Bezel Colour	Silver
Front Bezel Material	Metal
Front Dimension Concat	Ø 29,5mm
Front Form	Round
Ik Front Protection	Ik03
Lens Colour	Red
Lens Illumination	Non Illuminated
Lens Material	Plastic
Lens Shape	Flush
Max No Modules	6
Mechanical Lifetime	500 000 Cycles Of Operation
Mounting Cut Out Dps Concat	Ø 22mm
Operating Temperature	– 25 °c … + 55°C
Output Hsd	Yes
Protection Class	Ll
Shock Resistance	50g, 11ms (en-iec 60068-2-27)
Standards Norms	Csa C22-2, Iec En 60947-1, Iec En 60947-5-1, Ul508
Switching Action Concat	Maintained
Vibration Resistance	5g F= 2...500hz (en-iec 60068-2-6)
Weight	0.033
