Dehner Elektronik SDS 100L-12 DC/DC converter 8.4 A 100 W Content

Dehner Elektronik SDS 100L-12 is a highly efficient DC/DC converter that offers reliable performance for diverse power conversion needs. This direct current converter provides a maximum output of 8.4 A with a power rating of 100 W, making it suitable for applications requiring stable power delivery and voltage regulation. Built to cater to various industrial and engineering requirements, it ensures optimal power management in systems where conversion from one DC voltage level to another is necessary. Its compact design allows for easy integration into printed circuit boards, facilitating use in telecommunications, battery-powered devices, and other electrical systems requiring precise voltage calibration. The SDS 100L-12 is thus an ideal choice for engineers seeking robust and efficient power conversion capabilities.

Output Voltage	12V DC
Power Rating	100W
Connection	Screw terminal
Content	1
Dimensions	(L x W x H) 159 x 95 x 38 mm
Height	38mm
Input voltage (max.)	36V DC
Length	159mm
Max. operating temperature (derating)	70°C
Max. output current	8.4A
Min. input voltage	9.5V DC
Output current (max.) - rounded	8.4A
Output voltage (max.)	12V DC
Power	100W
Product Type	DC/DC converter
PSU features	DC-to-DC converter
Type	SDS 100L-12
Weight	460g
Width	95mm
