Chint 782005 NL210 RCCB 3PN 25A 100mA 10kA Protects Against Faults

Chint 782005 NL210 3PN 25A 100mA B 10kA RCCB, which is a residual current circuit breaker designed to provide protection against electric shocks and fire hazards by breaking the circuit when leakage is detected. It features a 3-pin configuration, is rated for 25 amperes, and has a fault current rating of 100 mA, ensuring reliability in industrial and commercial electrical systems. Typical applications for this product include safeguarding electrical installations in

Type	RCCB
No. of Poles	3
Tripping Characteristics	B Curve
Colour	Blue, White
Current Ratng	25A
Depth	79mm
Differential current rating	0.1A
Dim	(W x H x D) 72 x 91 x 79 mm
Height	91mm
Misc Attribute	B
Number of pins	3
Switch-off Capacity	10kA
Voltage Rating	415V
Width	72mm
