Block PVSE 230/24-5 DIN Rail PSU 24V DC 5A 120W Input 230/400VAC

Block
Order Code:

01-6396

Brand: Block MPN: PVSE 230/24-5

Discontinued


The Block PVSE 230-24-5 is a rail mounted PSU (DIN) offering 24 V DC output at 5 A with a total power of 120 W. Manufactured by Block, this industrial power supply unit is ideal for applications requiring reliable power delivery on a DIN rail. It features a single output and is commonly used in industrial settings for powering various control and automation equipment.
Type Rail mounted PSU (DIN)
Connection Spring-loaded terminal
Dim (L x W x H) 163.5 x 57 x 127 mm
Efficiency 87.8%
Height 127mm
Input Voltage 85 - 264 V/AC
120 - 373V DC
Input voltage (max.) 264V AC
Inputs 1
IP rating IP20
Length 163.5mm
Manufacturer part # PVSE 230/24-5
Max. output current 5A
Max. temperature 70°C
Min. input voltage 85V AC
Min. temperature -25°C
Misc Attribute PVSE 230-24-5
MTBF 500000h
No. of outputs 1
Nominal input voltage 100 - 240 V/AC
Output current (max.) - rounded 5A
Output voltage 24V DC
Output voltage (max.) 29.5V DC
Output voltage (min.) 22V DC
Output voltage (nominal) 24V DC
Phases 1
Power 120W
Weight 1100g
Width 57mm
