Alpha RV16AF-41-15R1-B25K Slide Potentiometers Linear Black 25K Ohm

Taiwan Alpha's RV16AF-41-15R1-B25K Slide Potentiometer is a linear variable resistor measuring 25K Ohms. This component, also known by its alternate description 1697974, is identified with the barcode 02050005494869 and Alternate Manufacturer Part Number RV16AF41B25KM. Designed for precise control in electronic circuits, the potentiometer features a reliable slide mechanism for adjusting resistance. Its robust construction makes it suitable for applications such as audio equipment, where volume control requires precision, or in instrumentation panels for adjusting signal levels accurately. Crafted to meet demanding engineering standards, this slide potentiometer provides engineers with dependable performance in both consumer electronics and industrial applications.

Type	Single turn rotary pot
Resistance	25kΩ
Power Rating	0.2W
Axle Diameter	6.35mm
Axle length	15mm
Connection	Print
Content	1
Maximum Temperature	70°C
Mechanical Angle	300°
Minimum Temperature	10°C
Output	Mono
Product Type	Single turn rotary pot
Resistance characteristic	linear
Thread Length	6.5mm
Thread Size	M7
