Alpha RV16AF-41-15R1-B10K Slide Potentiometer 10K Linear Horizontal Mount

Taiwan Alpha's RV16AF-41-15R1-B10K Slide Potentiometer is a linear, horizontal mount variable resistor designed for precise voltage and signal adjustment in electronic circuits. With its 10K ohm resistance, this potentiometer is engineered for reliable performance in fine-tuning applications, making it a suitable component for audio equipment, instrumentation, and control systems. The Taiwan Alpha RV16AF-41-15R1-B10K, also referred to by its alternate description number 1697973, integrates smoothly into circuit layouts where space is a premium due to its efficient form factor. It provides a robust solution for engineers requiring adjustable resistance in custom electronic designs or repairs.

Type	Single turn rotary pot
Resistance	10kΩ
Power Rating	0.2W
Axle Diameter	6.35mm
Axle length	15mm
Connection	Print
Content	1
Maximum Temperature	70°C
Mechanical Angle	300°
Minimum Temperature	10°C
Output	Mono
Product Type	Single turn rotary pot
Resistance characteristic	linear
Thread Length	6.5mm
Thread Size	M7
