Alpha RV16AF-41-15R1-A500K Slide Potentiometer 500K Linear Resistance

Taiwan Alpha's RV16AF-41-15R1-A500K Slide Potentiometer, also referenced as part number 1694259 or RV16AF41A500KM, is a precision-engineered variable resistor designed for linear resistance applications with a nominal resistance value of 500 kilo-ohms. This component features a slide type mechanism, allowing for smooth and precise adjustments in resistance, making it ideal for settings requiring frequent modulation of electrical resistance. The RV16AF-41-15R1-A500K is commonly employed in audio mixing consoles, instrumentation equipment, and industrial control systems where accurate and reliable resistance variation is crucial. Its robust construction ensures long-term stability and performance stability, even in demanding operational environments.

Type	Single turn rotary pot
Resistance	500kΩ
Power Rating	50mW
Axle Diameter	6.35mm
Axle length	15mm
Connection	Print (right-angle)
Content	1
Cross Section	5mm
Mechanical Angle	300°
Output	Mono
Product Type	Single turn rotary pot
Resistance characteristic	logarithmic
Thread Length	6.5mm
Thread Size	M7
