Alpha 63250-01600/B5K APM6B5KM Single turn rotary pot 0.2 W 5 kΩ Mono

Taiwan Alpha 63250-01600/B5K APM6B5KM is a single-turn rotary potentiometer designed for precision applications requiring variable resistance control. This component features a resistance value of 5 kO and is capable of handling a power rating of 0.2 watts, making it suitable for low-power circuits. Classified as a slide potentiometer, this device offers smooth and reliable operation within a compact form factor, catering to various industrial and consumer electronics applications. It is ideal for use in audio equipment for volume control, as well as in instrumentation and signal processing systems where precise adjustment is critical. Its robust design ensures reliable performance across its intended operating range, making it a trusted component in electrical circuit design.

Type	Single turn rotary pot
Resistance	5kΩ
Power Rating	0.2W
Axle Diameter	6mm
Axle length	30mm
Connection	Print
Content	1
Cut-off Voltage	200V
Maximum Temperature	70°C
Mechanical Angle	270°
Minimum Temperature	-25°C
Output	Mono
Product Type	Single turn rotary pot
Resistance characteristic	linear
Thread Length	8mm
Thread Size	M10
Tolerance ±	20%
Torque (max.)	2.0Ncm
