Alpha 63250-01600/B1M APM6B1MM Single turn rotary pot Mono 0.2 W 1 MΩ 1 pc

Taiwan Alpha's 63250-01600/B1M APM6B1MM is a single-turn rotary potentiometer, embodying precise control characteristics and robustness essential for engineering applications. It operates with a maximum power rating of 0.2 watts and a resistance value of 1 megaohm, providing reliable performance for variable resistance tasks in various electronic circuits. This slide potentiometer is particularly suitable for integration into audio equipment, instruments requiring fine-adjustment capabilities, and other electronic devices necessitating precise voltage or signal level control. The design ensures durability and consistent performance, making it an appropriate choice for professionals seeking dependable variable resistors.

Type	Single turn rotary pot
Resistance	1MΩ
Power Rating	0.2W
Axle Diameter	6mm
Axle length	30mm
Connection	Print
Content	1
Cut-off Voltage	200V
Maximum Temperature	70°C
Mechanical Angle	270°
Minimum Temperature	-25°C
Output	Mono
Product Type	Single turn rotary pot
Resistance characteristic	linear
Thread Length	8mm
Thread Size	M10
Tolerance ±	20%
Torque (max.)	2.0Ncm
