Alpha 63250-01600/B1K APM6B1KM Single turn rotary potentiometer 1 kΩ 200 mW

Taiwan Alpha 63250-01600/B1K APM6B1KM is a single-turn rotary potentiometer designed for precision variable resistance applications. This component features a resistance of 1 kO and a power rating of 200 mW, making it suitable for low-power circuits. The device operates as a slide potentiometer, offering reliable performance in adjusting voltage and current levels in various electronic configurations. It is frequently utilised in audio equipment, control panels, and instrumentation where fine-tuning of electrical signals is required. It is engineered for durability and consistency in operation, addressing the needs of both hobbyists and professionals in the electronics field.

Type	Single turn rotary pot
Resistance	1kΩ
Power Rating	200mW
Axle Diameter	6mm
Axle length	30mm
Connection	Print
Content	1
Cut-off Voltage	200V
Maximum Temperature	70°C
Mechanical Angle	270°
Minimum Temperature	-25°C
Output	Mono
Product Type	Single turn rotary pot
Resistance characteristic	linear
Thread Length	8mm
Thread Size	M10
Tolerance ±	20%
Torque (max.)	2Ncm
