Alpha 63250-01600/B10K Slide Potentiometer 10k Ohm Horizontal Mount

Taiwan Alpha 63250-01600/B10K is a precision slide potentiometer specifically designed for applications requiring a 10k ohm variable resistor with reliable horizontal mount capabilities. This component, also identified by the code 02050005494685 and alternate description 1697956, features high-quality construction suitable for precision control in electronic circuits. The potentiometer is engineered to provide smooth, linear voltage regulation, making it ideal for use in audio equipment, mixing consoles, and other devices where precise adjustment of electrical resistance is necessary. Its robust design ensures durability and consistent performance in demanding industrial and consumer electronics applications.

Type	Single turn rotary pot
Resistance	10kΩ
Power Rating	0.2W
Axle Diameter	6mm
Axle length	30mm
Connection	Print
Content	1
Cut-off Voltage	200V
Maximum Temperature	70°C
Mechanical Angle	270°
Minimum Temperature	-25°C
Output	Mono
Product Type	Single turn rotary pot
Resistance characteristic	linear
Thread Length	8mm
Thread Size	M10
Tolerance ±	20%
Torque (max.)	2.0Ncm
