Alpha 63250-01600/A1M single turn rotary potentiometer 0.05W 1MΩ 1pc

Taiwan Alpha 63250-01600/A1M, APM6A1MM, is a single-turn rotary potentiometer designed to provide reliable variable resistance for various electronic applications. This component, offering a resistance value of 1 MO and capable of handling a power rating of up to 0.05 watts, operates with precision and is well-suited for fine-tuning electrical signals in circuit designs. As a mono unit, it is typically employed in audio equipment to adjust volume levels, in instrumentation panels for precise calibration, and in control systems where variable resistance is required to modify circuit parameters. Its robust construction and efficient performance make it a valuable component for both hobbyist projects and professional electronic systems.

Type	Single turn rotary pot
Resistance	1MΩ
Power Rating	0.05W
Axle Diameter	6mm
Axle length	30mm
Connection	Print
Content	1
Cut-off Voltage	150V
Maximum Temperature	70°C
Mechanical Angle	270°
Minimum Temperature	-25°C
Output	Mono
Product Type	Single turn rotary pot
Resistance characteristic	logarithmic
Thread Length	8mm
Thread Size	M10
Tolerance ±	20%
Torque (max.)	2.0Ncm
