Weidmuller 7940006060 CB Cable Tie 430x4.8mm Ecru PA 6.6 100 pieces IEC62275

Weidmüller's product, the 7940006060 CB 430/4,8 cable tie, features a length of 430 mm and a width of 4.8 mm in an ecru colour. It is typically used for cable bundling and cable management, suitable for industrial applications. The package contains 100 pieces, offering a reliable solution for organising cables efficiently.

Length	430mm
Width	4.8mm
Colour	Ecru
Material	PA66
Type	Cable Ties
Band width	4.5
Basic material	Polyamide 66
Body Material	Polyamide 6/6
Bundle diameter	115 - 3.5
Bundle diameter, max.	115mm
Bundle diameter, min.	3.5mm
Cable diameter, max.	115mm
Certificate No. (UR)	E317499
Color	Natural
Depth	1.5mm
Depth (inches)	0.0591 inch
Dimensions	(W x H) 4.8 mm x 430 mm
ECLASS 14.0	27-14-07-02
ECLASS 15.0	27-14-07-02
ETIM 10.0	EC000046
ETIM 8.0	EC000046
ETIM 9.0	EC000046
Fluorescent	false
For re-opening	No
Gearing	Inside
GTIN (EAN)	4032248520251
Halogen	No
Halogen free	true
Height	430mm
Height (inches)	16.9291 inch
Inflammability class of insulation material according to UL94	V2
Length belt/tape/tie	430
Material quality	Polyamide (PA)
Max Operating Temperature	100°C
Max. bundle diameter	115mm
Max. sheet thickness	1.50mm
Max. temperature	+85°C
Min. temperature	-40°C
Minimum holding force	220N
Mounting temperature	-10 - 60
Net weight	2.92g
Operating Temperature	-40 - 85
Operating Temperature Range	-40...85°C
Operating temperature range, max.	85°C
Operating temperature range, min.	-40°C
Product Length (mm)	430
Qty.	100 items
REACH SVHC	No SVHC above 0.1 wt%
Releasable closure	false
ROHS	Conform
RoHS Compliance Status	Compliant without exemption
Surface protection	Plastic-coated
Tensile Strength	220 N
Tensile strength (Pound-force)	49 lbf
Text strip	None
Tie thickness	1.5
Transparent	false
Type of fastening	Other
UL 94 flammability rating	V-2
UL File Number Search	UL Website
UV-resistant	No
UV-stable according to ASTM D6779	false
Version	Cable ties, 4.5 x 430 mm, Polyamide 66, 220 N
Width (inches)	0.1772 inch
