WAGO 831-3626 Male MCS-MAXI 6P 7.62mm Angled Solder Pins

WAGO
Order Code:

57-0297

Brand: WAGO MPN: 831-3626 EAN-13: 4045454002213
Qty Unit Price (Ex VAT)
24+ £3.62
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 24
Available to back orderBack-order availability date - 25/04/2026

THT male header; 1.0 x 1.2 mm solder pin; angled; 100% protected against mis-mating; Pin spacing 7.62mm; 6-pole; light grey.

  • Colour: Light grey
  • Contact material: Cathode copper, tin plated
  • Height (from surface): 14.8mm
  • Width: 48.6mm
  • Depth: 29mm
  • Grid pitch: 7.62mm
  • Number of contacts: 3/pole
  • Weight: 15.5g
  • Manufacturer Part: 831-3626
Body Style Horizontal Closed End Header
Pitch 7.62mm
No of Ways Per Row 6
Current Rating 41 A
Colour Grey
Wire Gauge (mm²) N/A
Category PCB Terminal Blocks and Connectors;Pluggable Connectors
Depth inch 1.142 inches
Depth mm 29mm
Flammability class according to UL94 V0
Height inch 0.74 inches
Height mm 18.8mm
Rated surge voltage (II / 2) 6 kV
Rated voltage (II / 2) 1000 V
Total number of potentials 6
Unit Weight KGM
Weight 15.510 g
Width inch 1.913 inches
Width mm 48.6mm
