WAGO 733-202 Male MCS-MICRO 2P 2.5mm Horizontal Mount

WAGO
Order Code:

57-0944

Brand: WAGO MPN: 733-202 EAN-13: 4044918849524
Qty Unit Price (Ex VAT)
200+ £2.48
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 200
Available to back orderBack-order availability date - 26/04/2026


  • AWG size: 20
  • Colour: Light grey
  • Contact material: Cathode copper
  • Dimensions, length: 11.8mm
  • Dimensions, width: 7.5mm
  • Grid pitch: 2.5mm
  • Number of contacts: 2
  • Stripping length: 6mm
  • Type (manufacturer type): 733-202
  • Weight: 1.2g
Body Style Horizontal Closed End Header
Pitch 2.5mm
No of Ways Per Row 2
No. of Rows 1
Current Rating 6 A
Colour Grey
Wire Gauge (AWG) 28 AWG
Wire Gauge (mm²) 0.08 mm²
Category PCB Terminal Blocks and Connectors;Pluggable Connectors;Lighting Connection
Connection CAGE CLAMP®
Depth inch 0.799 inches
Depth mm 20.3mm
Dimensions length: 11.8mm
Flammability class according to UL94 V0
Height inch 0.465 inches
Height mm 11.8mm
Rated surge voltage (II / 2) 2.5 kV
Rated voltage (II / 2) 320 V
Stripping length 6mm
Stripping length of 1 mm 5mm
Stripping length up to 1 mm 6mm
Total number of potentials 2
Type of operation Operating tool
Unit Weight KGM
Weight 1.200 g
Width inch 0.295 inches
Width mm 7.5mm
