WAGO 2721-202/026-000 Female MCS-MIDI 2P 7.5mm Push Buttons

WAGO
Order Code:

57-0542

Brand: WAGO MPN: 2721-202/026-000 EAN-13: 4045454745097
Qty Unit Price (Ex VAT)
100+ £1.50
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 100
Available to back orderBack-order availability date - 09/04/2026


  • AWG size: 12
  • Colour: Light grey
  • Contact material: Copper alloy
  • Dimensions, length: 15mm
  • Dimensions, width: 14mm
  • Number of contacts: 2
  • Stripping length: 11mm
  • Type (manufacturer type): 2721-202/026-000
  • Weight: 3.92g
Body Style Female connector/socket
Pitch 7.5mm
No of Ways Per Row 2
No. of Rows 1
Current Rating 16 A
Colour Grey
Wire Gauge (AWG) 24 AWG
Wire Gauge (mm²) 0.2 mm²
Category PCB Terminal Blocks and Connectors;Pluggable Connectors
Connection Push-in CAGE CLAMP®
Depth inch 1.008 inches
Depth mm 25.6mm
Flammability class according to UL94 V0
Height inch 0.591 inches
Height mm 15mm
Rated surge voltage (II / 2) 6 kV
Rated voltage (II / 2) 1000 V
Stripping length of 1 mm 10mm
Stripping length up to 1 mm 11mm
Total number of potentials 2
Type of operation Push-button
Unit Weight KGM
Weight 3.816 g
Width inch 0.551 inches
Width mm 14mm
