WAGO 2231-104/102-000 Female End Plate 4P Pitch 5mm Push-button

WAGO
Order Code:

57-1250

Brand: WAGO MPN: 2231-104/102-000 EAN-13: 4045454907648
Qty Unit Price (Ex VAT)
100+ £2.40
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 100
Available to back orderBack-order availability date - 04/05/2026


  • Number of Poles: 4
  • Pitch 5mm
  • AWG size: 12
  • Colour: Grey
  • Contact material: Copper alloy
  • Dimensions, length: 15mm
  • Dimensions, width: 20mm
  • Number of contacts: 4
  • Stripping length: 11mm
  • Type (manufacturer type): 2231-104/102-000
  • Weight: 6.36g
  • Pack Size: 100
Body Style Female connector/socket
Pitch 5mm
No of Ways Per Row 4
No. of Rows 1
Current Rating 16 A
Colour Grey
Wire Gauge (AWG) 24 AWG
Wire Gauge (mm²) 0.2mm²
Category PCB Terminal Blocks and Connectors;Pluggable Connectors;Lighting Connection
Connection Push-in CAGE CLAMP®
Depth 25.6mm
Depth inch 1.008inches
Flammability class according to UL94 V0
Height 15mm
Height inch 0.591inches
Rated surge voltage (II / 2) 4 kV
Rated voltage (II / 2) 630 V
Stripping length of 1 mm 10mm
Stripping length up to 1 mm 11mm
Total number of potentials 4
Type of operation Push-button
Unit Weight KGM
Weight 6.152g
Width 20mm
Width inch 0.787inches
