TruComponents 751507 Toggle switch Panel Mount On/Off/On DPDT Solder Terminal

TruComponents
Order Code:

75-1507

Brand: TruComponents MPN: 751507 EAN-13: 4064161162072
Qty Unit Price (Ex VAT)
1+ £4.96
5+ £4.41
10+ £4.05
25+ £3.82
50+ £3.61
100+ £3.48
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
619 available to back orderBack-order availability date - 09/01/2026

The TruComponents 751507 Toggle Switch is a high-quality, reliable component designed for a wide range of applications. This Single Pole Double Throw (SPDT) switch offers an On/On functionality, making it ideal for controlling two different circuits with a single switch. The chrome-plated toggle has a removable red insulating sleeve.
Contact Configuration 2 x On/Off/On
Switch Function latch/0/latch
Current Rating (Amps) 3A
Actuator Type Steel lever (insulated)
Termination Style Solder tag
Casing/button colour Red
CS 4.7mm
Dim (L x W x H) 13 x 12.73 x 32.85 mm
Height 32.85mm
Industrial packaging Compatible with
Length 13mm
Lighting type None
Max. temperature 80°C
Min. temperature -10°C
Misc Attribute TC-9354000
Number of Pins 6
Recess depth 13.46mm
Recess diameter 6.35mm
Switching Voltage 250V AC
Type Toggle switch
Width 12.73mm
