TruComponents 751504 Toggle switch Panel Mount On/Off/(On) SPDT Solder Terminal

TruComponents
Standard range
Order Code:

75-1504

Brand: TruComponents MPN: 751504 EAN-13: 4064161162041
Qty Unit Price (Ex VAT)
1+ £4.00
5+ £3.56
10+ £3.27
25+ £3.08
50+ £2.91
100+ £2.81
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2,264 in stock, despatched in 4 working days

The TruComponents 751504 Toggle Switch is a high-quality, reliable component designed for a wide range of applications. This Single Pole Double Throw (SPDT) switch offers an On/On functionality, making it ideal for controlling two different circuits with a single switch. The chrome-plated toggle has a removable red insulating sleeve.
Type Toggle switch
Casing/button colour Red
Connection Solder tag
CS 4.7mm
Dim (L x W x H) 13 x 7.9 x 32.85 mm
Functions latch/0/momentary
Height 32.85mm
Industrial packaging Compatible with
Length 13mm
Lighting type None
Max. temperature 80°C
Min. temperature -10°C
Misc Attribute TC-9353988
Number of pins 3
Recess depth 13.46mm
Recess diameter 6.35mm
Switch position 1 x On/Off/(On)
Switching current (max.) 3A
Switching voltage 250V AC
Width 7.9mm
