TracoPower TXM 150-112 SMPSU 150W 12V 12.5A Compact Metal Casing High Efficiency

TracoPower
Standard range
Order Code:

07-8457

Brand: TracoPower MPN: TXM 150-112
Qty Unit Price (Ex VAT)
1+ £79.72
5+ £77.33
10+ £74.94
25+ £71.80
50+ £68.56
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

The TracoPower TXM 150-112 is a printed circuit board power supply unit producing 12 V DC at 12.5 A with a power output of 150 W. This SMPSU features a PCB mount design with solder lugs for secure connections. It is typically used in industrial and commercial equipment, including LED lighting, control systems, and automation applications.
Type SMPSU
Connection Screw terminal
Dim (L x W x H) 38.0 x 98.3 x 160.0 mm
Height 160.0mm
Input voltage (max.) 264V AC
Length 38.0mm
Max. operating temperature (derating) 50°C
Max. output current 12.5A
Min. input voltage 85V AC
Min. operating temperature (derating) -20°C
Misc Attribute 1 TXM 150-112
Misc Attribute 2 closed
No. of outputs 1
Operating temperature (max.) 60°C
Output current (max.) - rounded 12.5A
Output current (min.) 0mA
Output voltage (max.) 12V DC
Power 150W
Weight 625g
Width 98.3mm
